SolidWorks Sketch Relations and Constraints — Episode 3 Beginners Guide (Updated June 2026)

I get this question all the time from students: "My sketch looks right but SolidWorks won't let me extrude it — what's wrong?" Nine times out of ten, the sketch is under-defined. And that's exactly what Episode 3 fixes. Here's the thing — the AURIC manufacturing zone in Sambhajinagar has attracted ₹71,343 crore in investment with 62,405 jobs lined up, and every manufacturer from Skoda Volkswagen to Bajaj Auto needs design engineers whose SolidWorks sketches are fully defined, dimensionally correct and ready for manufacturing the first time. Sketch relations are the foundation — get them right and everything else in SolidWorks becomes faster.

▶ Watch on YouTube

Why Sketch Relations Are the Most Important SolidWorks Skill Nobody Teaches First

Most SolidWorks beginners jump straight to drawing lines and circles without understanding what keeps them in place. A sketch in SolidWorks is parametric — that means every line, arc and circle has a position that is controlled either by dimensions or by geometric relations (constraints). If you add a circle to a sketch and only give it a diameter dimension, it can still slide anywhere on the sketch plane. That's an under-defined sketch. When you add a coincident relation between the circle's centre and the origin, suddenly it's locked in place. Combine that with the diameter dimension, and your sketch turns completely blue — fully defined. Manufacturers like Mahindra's Chakan plant and L&T's engineering division expect design files where every sketch is fully defined before the model is released for tooling. Episode 3 shows you exactly how to get there.

Coincident, Collinear and Midpoint Relations — Making Points Behave

Coincident is the most-used sketch relation in SolidWorks — it forces two points to occupy the same location. Select an endpoint from one line and the midpoint of another, apply Coincident, and they snap together. Collinear forces two or more line segments to lie on the same infinite line, which is useful when designing stepped shafts and symmetric profiles. Midpoint relation places a point exactly at the centre of a line segment — essential when you need to anchor a feature on the centreline of a symmetric part. These three relations together handle about 60% of basic sketch definitions. Practice them on a simple flange profile, the same type of part you'd design for Bajaj Auto's Waluj press shop or Endurance Technologies' stamping line at Plot E-92, Sambhajinagar.

Parallel, Perpendicular and Equal Relations — Controlling Line Directions

Parallel relation forces two lines to remain parallel regardless of how you drag either line. Perpendicular forces a 90-degree angle between them. Equal relation makes two or more lines (or arcs) the same length (or radius) automatically — add one dimension and all equal entities update together. This is powerful when designing symmetric pockets, equally-spaced holes or uniform rib patterns. What most people don't realize is that Equal and Parallel together can eliminate dozens of redundant dimensions. Instead of dimensioning every rib width separately on a gearbox housing, apply Equal across all ribs and dimension just one. Bosch India's design standards and Siemens' component drawing guidelines both encourage minimal-dimension sketches that rely on geometric relations — your drawings look cleaner and your models update faster.

Tangent and Concentric Relations — Working with Arcs and Circles

Tangent relation is what you use when an arc must smoothly meet a line without a visible kink at the junction — this is critical for any profile that will be manufactured by CNC turning or milling. If your arc and line are tangent in SolidWorks, the G1 continuity is guaranteed and your CAM software won't generate a tool path kink at that transition. Concentric forces two circles or arcs to share the same centre point — essential for boss-and-hole pairs, O-ring grooves and bearing housings. I see beginners skip Tangent and instead dimension the arc endpoint to the line endpoint, which looks right on screen but breaks apart when the arc radius changes. Trust me — use the Tangent relation and let the geometry sort itself out.

Symmetric and Fix Relations — Advanced Control for Precision Designs

Symmetric relation places two entities symmetrically about a centreline, which is the proper way to design any mirrored feature. Select your centreline first, then the two entities, then apply Symmetric. The entities will mirror automatically whenever you drag either side. Fix relation pins a point or entity to an absolute location on the sketch plane — use it sparingly, only when you genuinely need a point anchored regardless of other dimensions. Most of the time, Fix is a crutch; proper dimensions and relations are the right approach. The one legitimate use for Fix is locking a reference geometry point that you're importing from another part in an assembly context — which you'll see in Episode 7 when we build our first assembly at ABC Trainings.

How to Check if Your Sketch Is Fully Defined Before Extruding

SolidWorks gives you clear visual feedback on sketch definition status. Black lines are fully defined. Blue lines are under-defined and can still be dragged. Red lines are over-defined — you've applied conflicting relations or redundant dimensions and SolidWorks doesn't know which to obey. To check definition status, open the Sketch Status panel at the bottom of the screen. You'll see "Fully Defined", "Under Defined" or "Over Defined". Never extrude an under-defined sketch into a production model — the geometry can shift when you regenerate the model or change a parent dimension. Make it a habit: sketch is blue and fully-defined before you exit sketch mode. This discipline is what separates professional SolidWorks users at KPIT and Tata Technologies from hobbyists.

FAQs

What is the difference between a sketch relation and a dimension in SolidWorks?

A sketch relation (constraint) controls the geometric behaviour of entities — for example, making two lines parallel or forcing a point to lie on another line. A dimension controls size — the length of a line or the diameter of a circle. Fully defining a sketch requires both: relations to lock the shape and dimensions to lock the size. You can use fewer dimensions if you use more relations, which is generally cleaner.

How do I know if my SolidWorks sketch is fully defined?

SolidWorks uses colour coding to show sketch definition status. Fully-defined geometry turns blue. Under-defined geometry stays black or yellow. Over-defined geometry turns red. You can also check the bottom status bar of the SolidWorks window — it displays "Fully Defined", "Under Defined" or "Over Defined" while you're in sketch mode. Always aim for fully defined (all blue) before exiting the sketch.

Can I delete a sketch relation after I apply it?

Yes — right-click on any entity in the sketch to see its applied relations in the Properties panel, or open Display/Delete Relations from the Sketch toolbar. Select the relation you want to remove and click Delete. Be careful: removing a relation may make your sketch under-defined, so you may need to add a dimension to compensate.

Which SolidWorks sketch relation is used most often in real engineering drawings?

Coincident is by far the most used sketch relation in real engineering drawings — it's used to anchor the sketch to the origin, connect endpoints of adjacent lines, and place holes on centrelines. After Coincident, Tangent is the next most common in product design work, particularly for parts that involve curved profiles machined on CNC turning or milling centres.
