SolidWorks Simulation for Mechanical Engineers — Episode 10 Beginners Guide (Updated June 2026)

Here's the thing — when companies like Tata Technologies or KPIT interview a mechanical design engineer, they almost always ask: "Have you done any FEA work in SolidWorks?" What most freshers don't realize is that the AURIC zone in Sambhajinagar has attracted ₹71,343 crore in investment with 62,405 manufacturing jobs in the pipeline — and every one of those manufacturers wants design engineers who can validate parts before production, not after. SolidWorks Simulation is that validation tool, and Episode 10 of our beginners series walks you through your first complete FEA study from scratch.

▶ Watch on YouTube

What Is SolidWorks Simulation and Why Manufacturers Demand It

SolidWorks Simulation is a Finite Element Analysis module that divides your 3D model into thousands of small mathematical elements called a mesh, then calculates how forces flow through each element when you apply a load. The result? You know exactly where your design will fail before you spend a single rupee on raw material or machining. That's why companies like Bosch India, Siemens, Force Motors and Bharat Forge — all active across Maharashtra — have made FEA sign-off mandatory in their design approval workflows. The good news is that this episode is built specifically for people who have never run a simulation study before. By the end of Episode 10, you'll have completed your first static analysis on a real mechanical part, and you'll understand how to interpret what the software is telling you.

Setting Up a Static Study: Fixtures, Loads and Mesh Explained

When you open a Simulation study in SolidWorks, you'll see three folders in the Simulation tree: Fixtures, External Loads and Mesh. Trust me — the order matters. Step one: right-click Fixtures and apply a Fixed Geometry constraint to the face or edge that doesn't move in real life. Step two: apply your force or pressure under External Loads. Step three: mesh the model using Mesh → Create Mesh. Most beginners skip the fixture step and then wonder why their results show the entire part flying off into space — that's because without a fixture, there's nothing anchoring the model. For Episode 10, we work through a steel mounting bracket — the same type of part used on production lines at Bajaj Auto's Akurdi plant and at Mahindra's Chakan manufacturing facility outside Pune.

How to Assign Materials and Define Boundary Conditions Correctly

SolidWorks includes a material library with over 700 options. What most people don't realize is that choosing the wrong material doesn't just affect the numbers on screen — it can invalidate your entire design approval. If your engineering drawing specifies AISI 4140 chrome-moly steel but you simulate with a generic Alloy Steel entry, the yield strength values differ enough to give you a dangerously optimistic factor of safety. Always navigate to SolidWorks Materials → Steel and pick the exact grade matching your drawing. If your specific grade isn't listed, request the material certificate from your supplier and enter the tensile strength, yield strength, elastic modulus and Poisson's ratio manually. Bosch India's vendor qualification forms actually ask which material grade was used in the FEA sign-off, so accuracy here is genuinely non-negotiable.

Reading Your Stress, Displacement and Factor of Safety Results

After running the study, SolidWorks displays three key outputs: Von Mises stress (combined stress state at each point, shown in N/mm² or MPa), Resultant Displacement (how much each node moved, in mm) and Factor of Safety. Here's how to read them: if your maximum Von Mises stress is 180 MPa and your material's yield strength is 250 MPa, your factor of safety is approximately 1.39 — borderline for most structural applications. Aim for FOS of at least 2 for general machine components, and FOS of 3–4 for safety-critical parts. Red zones in the stress plot flag stress concentrations — check whether they're at expected stress raisers like holes and fillets. If they appear somewhere unexpected, your fixture or load application may be wrong and you should revisit the setup before trusting the results.

Pune and Sambhajinagar Companies Hiring Engineers with FEA Skills

With ₹71,343 crore of manufacturing investment flowing into the AURIC zone, companies actively hiring FEA-capable engineers include Skoda Volkswagen at Shendra (Plot A-1/1), Bajaj Auto at Waluj (Plot G-137), Endurance Technologies (Plot E-92), Hyosung's ₹3,000 crore Maharashtra facility, and Toyota Kirloskar's AURIC campus. In Pune, Tata Technologies at Hinjewadi Phase 1, KPIT Technologies at Koregaon Park, Whirlpool India at Ranjangaon, and Mercedes-Benz R&D India all list SolidWorks Simulation as a preferred skill. PayScale data puts entry-level design engineers with simulation exposure at ₹3.8–₹5.2 LPA in Pune, rising to ₹8–₹12 LPA with 3–4 years of project experience. AmbitionBox shows similar roles in Sambhajinagar at ₹3.2–₹4.8 LPA for mechanical design trainees.

Common FEA Mistakes Beginners Make — and How to Avoid Them

After training hundreds of engineers at ABC Trainings, here are the four mistakes I see most often. First, no fixture defined — without anchoring the model, SolidWorks cannot compute meaningful deformation or stress. Second, mesh too coarse near stress concentrations — always use Mesh Control to reduce element size near holes, fillets and notches to at least one-third of the feature radius; coarse mesh misses peak stress by 30–40%. Third, wrong load units — confirm your force input is in Newtons, not kilonewtons, before clicking Run. Fourth, not knowing your material's yield strength before interpreting the factor of safety — without that reference value, the colour plot is decorative, not informative. These four checks take two minutes each and prevent hours of troubleshooting.

FAQs

Is SolidWorks Simulation available in the standard SolidWorks licence?

SolidWorks Simulation is included in the Premium and Professional editions, not the Standard licence. At ABC Trainings, our labs run SolidWorks Premium so students get full simulation access throughout the course. After completing, many students continue practising on their college licence or the 30-day Dassault evaluation version.

What is Von Mises stress and why does SolidWorks use it?

Von Mises stress is a mathematical formula that combines all six stress components — normal stresses in X, Y and Z directions plus three shear stresses — into a single equivalent value. Engineers compare this value against the material's yield strength. If Von Mises stress exceeds yield strength, the material will deform permanently. It is the most practical FEA output for ductile metals like steel and aluminium, which is why SolidWorks displays it by default.

Can a fresher mechanical engineer get a job in Pune with SolidWorks Simulation skills?

Yes, and demand is growing. Companies like Tata Technologies, KPIT, Mahindra Engineering Services and L&T Technology Services list SolidWorks and Simulation in entry-level design engineer job descriptions. AmbitionBox shows these roles pay ₹3.5–₹5 LPA at fresher level, with performance-linked increments every six months at Tier-1 engineering service firms.

How long does it take to become proficient at SolidWorks FEA?

The core concepts — static study setup, material assignment, loads, fixtures and result interpretation — can be learned in 4–6 weeks with consistent daily practice. Our Episode 10 video is designed to get you through your first complete simulation study in one sitting. Add another 4–6 weeks for thermal and frequency studies. The rest is practice on your own part models.
