CAD file formats are one of those things that trip up almost every mechanical engineering student — and honestly, quite a few working engineers too. You model a part in SolidWorks, send a STEP file to your vendor, and suddenly their software cannot open it correctly. Or you try to submit a DXF for laser cutting and the machine operator calls back saying the file has open contours. I have been training mechanical engineers and students on CAD software for over 12 years, and this question — which file format should I use? — comes up in every single batch. The good news is that once you understand the logic behind the seven most common formats, the choice becomes obvious every time. Here is everything you need to know, with clear comparisons and real-world use cases from the Pune manufacturing and design industry.

Why CAD File Format Knowledge Is a Real Job Skill

In Pune's manufacturing ecosystem — from Bajaj Auto Akurdi to Tata Motors Ranjangaon, from Mahindra Chakan to Bosch Hadapsar — design engineers work with vendors and suppliers who use different CAD tools. A product designer at Mahindra might model in CATIA V5. Their die-casting vendor might work in SolidWorks. Their sheet metal supplier might use SolidEdge. Getting the geometry across these platforms without data loss is a daily task, and knowing which format to send — and how to verify the conversion — is the difference between a smooth workflow and a week of back-and-forth emails. Companies like Skoda VW Shendra and Tata Tech specifically list CAD data management and file conversion as part of their senior designer job descriptions.

Format	Type	Best Use	Preserves Feature History?	Common Software
STEP (.stp)	3D Solid	Cross-platform geometry exchange	No (geometry only)	All major CAD tools
IGES (.igs)	3D Surface	Legacy surface data exchange	No	CATIA, older CAD
STL (.stl)	3D Mesh	3D printing, CFD mesh	No	All CAD, slicers
DWG	2D Drawing	Engineering drawings, construction	N/A	AutoCAD, SolidWorks export
DXF	2D Open Exchange	Laser/CNC cutting profiles	N/A	All CAD, CNC machines
Native (SLDPRT/CATPart)	3D Parametric	Internal team design work	Yes	SolidWorks / CATIA only
PDF / eDrawings	Review/Approval	Customer sign-off, design review	No	Any viewer, eDrawings

Format 1 — STEP (.stp / .step): The Universal 3D Standard

STEP (Standard for the Exchange of Product Data) is the most reliable format for sharing solid 3D geometry between different CAD platforms. It preserves solid body geometry, surfaces, and in newer versions (AP242) even some feature data and Product Manufacturing Information (PMI). Use STEP when: sending a 3D solid model to a vendor using different software; sharing geometry with FEA software like ANSYS or Nastran; submitting to a customer for design review. In SolidWorks, export via File → Save As → STEP AP214 or AP242. In CATIA, use File → Save As → stp. Always verify the export by opening the file in a neutral viewer like eDrawings or a free STEP viewer before sending. STEP is the format that Mahindra Research Valley and L&T Engineering specify in their supplier data package requirements.

Format 2 — IGES (.igs / .iges): The Legacy Surface Format

IGES (Initial Graphics Exchange Specification) is an older format that pre-dates STEP and is still widely used for surface-only data exchange — particularly between software like CATIA V4/V5 and older design tools. The key limitation of IGES: it does not reliably transfer solid body topology (the B-Rep structure that makes a model a closed solid). You may open an IGES file and find a collection of surfaces rather than a solid. For mechanical parts with complex Class-A surfaces — like automotive exterior body panels — IGES is still sometimes preferred because it handles surface patches well. But for general solid mechanical parts, STEP is always the better choice. If someone sends you an IGES file that opens as an open surface, try using the Surface Fill or Knit tool in SolidWorks to close it into a solid.

Format 3 — STL (.stl): Built for 3D Printing and Mesh Simulation

STL (Stereolithography) is a mesh format that represents geometry as a collection of triangular facets. It has no concept of dimensions, tolerances, feature history, or parametric data — just a shell of triangles. Use STL exclusively for 3D printing (FDM, SLA, SLS) and mesh-based simulation (like CFD or crash analysis). Never use STL for engineering drawings or manufacturing dimensions. When exporting STL from SolidWorks or CATIA, set the resolution to Fine — coarse resolution creates visible faceting on curved surfaces that ruins the print. Check the exported file in a slicer (like Ultimaker Cura or PrusaSlicer) before sending it to the printer to catch any mesh errors or open surfaces that will cause print failures.

Format 4 — DWG: AutoCAD Native 2D Drawing Format

DWG is AutoCAD's native file format for 2D engineering drawings and is the industry standard for construction drawings, layout plans, and CNC machining drawings. Every civil, mechanical, and electrical engineer working in Pune's manufacturing or infrastructure sector will encounter DWG files regularly. L&T, AECOM, Pune Municipal Corporation, and Maharashtra PWD projects typically specify DWG format for all drawing submissions. DWG versions matter — AutoCAD 2018 DWG files will not open in AutoCAD 2014 without a downgrade save. When sharing DWG files with external parties, save to AutoCAD 2013 or earlier format to ensure maximum compatibility. In SolidWorks, you can export 2D drawings as DWG via File → Save As → DWG with the option to map drawing views to AutoCAD layers.

Format 5 — DXF: The Open 2D Exchange Format

DXF (Drawing Exchange Format) is Autodesk's open format for 2D geometry exchange, designed specifically to be read by non-AutoCAD software — laser cutters, plasma cutters, waterjet machines, and CNC routers all typically import DXF. The key difference from DWG: DXF is text-based and fully documented, so virtually any CAD software can read it. When sending profiles for laser cutting at Pune's fabrication shops, always send DXF and confirm that all profile lines form closed contours with no gaps. Open contours will cause the laser to make incorrect cuts. In SolidWorks, use Insert → DXF/DWG to import; for export, save your sketch or drawing sheet as DXF directly. Check the exported file in a DXF viewer before sending to confirm all entities are correct.

Format 6 — Native Formats: SLDPRT, CATPart, and When to Use Them

Native formats — SolidWorks .SLDPRT and .SLDASM, CATIA .CATPart and .CATProduct, Fusion 360 .f3d — preserve full parametric feature history, design intent, configurations, and all modelling data. These are the gold standard for internal project work where everyone uses the same software. Never exchange native files with external parties unless you have confirmed they use the same software version — CATIA V5 R28 files will not open in CATIA V5 R20, and SolidWorks 2024 files will not open in SolidWorks 2022 without saving down. For Pune-based OEM design teams at Bajaj Auto and Mahindra who maintain long-term supplier relationships, native format libraries are often part of the supplier quality agreement. Keep a version-controlled native file archive and export STEP or DWG copies for vendor use.

Format 7 — PDF and eDrawings: The Approval and Review Format

PDF for engineering drawings is commonly misunderstood. A PDF generated from a CAD tool is a read-only review document — it cannot be imported back into CAD for editing without significant quality loss. Use PDF for customer sign-off, approval cycles, and sharing drawings with non-engineering stakeholders. eDrawings (.eprt, .easm) is the SolidWorks-native review format that allows non-CAD users to rotate, measure, and interrogate 3D models and 2D drawings without requiring a full SolidWorks licence. It is the format of choice for design review meetings at Tata Technologies and Mahindra. Use File → Publish to eDrawings in SolidWorks to generate the file. The free eDrawings viewer is available for Windows, Mac, iOS, and Android.

How to Choose the Right Format and Convert Safely

Here is a practical format decision tree: sending a 3D solid model to a vendor using different software — use STEP AP214 or AP242. Sending for 3D printing — use STL at Fine resolution. Sending 2D drawings for manufacturing or construction — use DWG (save to 2013 format for compatibility). Sending a cutting profile to a laser or CNC shop — use DXF with verified closed contours. Sending for design review or approval — use PDF or eDrawings. Working within the same team on the same software — use native format with version control. For conversion, always verify by opening the output file in a neutral viewer before sending. At ABC Trainings Wagholi, our SolidWorks and CATIA courses include a full module on file management and format conversion — it is one of the most practical skills that makes a real difference on your first week at work.

Students and recent graduates in Maharashtra looking to build professional CAD file management and conversion skills can explore the CMYKPY stipend scheme (₹6,000–₹10,000/month during approved training) and PMKVY 4.0-aligned programs. ABC Trainings Wagholi can guide you on current enrollment options and eligibility — practical CAD training with file format and conversion modules is part of our standard course curriculum.

FAQs

What is the difference between STEP and IGES in CAD and which should I use?

STEP (AP214 or AP242) is the modern standard for solid 3D geometry exchange between different CAD platforms. It reliably transfers solid bodies and surfaces. IGES is an older format better suited to surface-only data and legacy software compatibility. For almost all practical purposes, use STEP for 3D model exchange — it has broader support, smaller file sizes, and better solid body fidelity. Only use IGES if the receiving party specifically requests it or is on older software that does not support STEP AP242.

Can I convert a SolidWorks part to CATIA without losing the model data?

Direct conversion between SolidWorks and CATIA native formats is not possible without losing feature history. The standard workflow is to export from SolidWorks as STEP AP214 and import into CATIA. The receiving software will see the geometry as a dumb solid (no features, just a body), which is sufficient for most manufacturing and downstream analysis work. If you need editable features in CATIA, the model must be rebuilt from scratch in CATIA — there is no automated parametric translation between the two.

Why does my STL file have gaps when I open it in the 3D printer slicer?

Gaps in STL files (also called open meshes or non-manifold geometry) almost always originate from the source CAD model having geometry issues — small gaps between surfaces, zero-thickness faces, or non-manifold edges. The fix: before exporting STL, run Check Geometry in SolidWorks (Evaluate → Check) or the Geometry Checker in CATIA. Repair any flagged issues in the native model, then re-export. Also verify the export resolution is set to Fine, not Coarse — coarse resolution can create mesh mismatches at curved surface boundaries.
