NX CAD Episode 7: Extrude & Revolve — Core 3D Modeling Commands Mastered (Updated June 2026)

Most NX beginners think Extrude means 'push a sketch up' and Revolve means 'spin a sketch around an axis.' That understanding gets you through the tutorials. What gets you through a technical interview at Bajaj Auto, Tata Technologies, or Bosch is knowing every option, every limit type, every manufacturing consideration baked into these two fundamental commands. Episode 7 of our Foundation to Expert NX CAD series treats Extrude and Revolve the way they deserve — as complex, powerful operations with dozens of options that experienced engineers use daily. With Maharashtra's manufacturing sector creating 62,405 jobs through AURIC investments, and NASSCOM projecting 1.25 million new engineering roles requiring digital design skills by 2027, there's never been a better time to build your 3D modeling foundation properly.

▶ Watch on YouTube

NX CAD Episode 7: Extrude and Revolve — Every Option Explained

Episode 7 is structured around a single principle: never use default options blindly. The episode covers every parameter in both Extrude and Revolve, explaining what each does, why you would choose it, and what manufacturing implication it carries. The exercise projects are a cast bracket (using draft angle Extrude), a turned shaft component (using Revolve), and a simple housing block (combining both). By the end, students can look at any prismatic or axisymmetric part and immediately identify which combination of Extrude and Revolve options to use — the mental model that accelerates all subsequent learning.

Extrude Limit Types in NX: Value, Until Next, Until Last & Until Extended

NX Extrude offers six limit types that control how far the extrusion extends. Value is the default — you type a number. Until Next stops the extrusion at the first face it encounters, which is critical for designs where a pocket must always reach the next internal partition regardless of how thick that partition is. Until Last extends to the last face — useful for through-holes that must exit the part completely even if the wall thickness changes during design iteration. Until Extended stops at a mathematically extended version of a face, even if the actual face doesn't reach the extrusion. Between Extents lets you define both the start and end independently. Symmetric extrudes equally in both directions from the sketch plane — ideal for symmetric parts that must remain balanced. Episode 7 demonstrates why choosing Until Next instead of Value can prevent an entire category of assembly clash failures during design revision.

Draft Angle, Offset & Symmetric Extrude: Manufacturing-Ready Options in NX

Draft angle is how you make an injection-molded or die-cast part eject from its mold. In NX Extrude, you specify a draft angle (typically 0.5–3 degrees for plastic, 1–5 degrees for die casting) and a draft direction, and NX automatically tapers the side walls of your extrusion. Episode 7 covers both outward draft (walls taper away from the profile, making the part wider at the base — for ejection from a top-pull mold) and inward draft (walls taper inward — for side-action molds). Offset Extrude thickens a surface sketch into a solid with a specified wall thickness — essential for thin-shell plastic parts like enclosure covers. These options are what separate a modeling student from a production engineer.

Revolve in NX: Axis Selection, Angle Limits & Bi-Directional Revolve

Revolve in NX takes a sketch profile and rotates it around a specified axis through a given angle — creating axisymmetric solids like shafts, wheels, pulleys, flanges, and valve bodies. Episode 7 covers axis selection (the axis can be an edge, a datum axis, or a line in the sketch — each has different implications for model stability); angle limits (you can revolve any angle from 0 to 360 degrees in either direction, or specify start and end angles); and bi-directional Revolve (which extends the rotation equally in both directions from 0 degrees — ideal for symmetric revolves like a lens or a dome). The episode also covers combining Revolve with Boolean operations: adding a revolved boss to an existing body (Unite), cutting a revolved groove from a body (Subtract), and creating a revolved insert that combines with an Extrude base.

NX CAD Fresher Jobs in Maharashtra: First Roles, Salaries & Employers

For freshers, NX CAD modeling skills open entry-level positions at: KPIT Technologies (Hinjewadi, Pune) — engineering services for automotive OEMs, freshers at ₹3.2–4.8 LPA; Tata Technologies (Hinjewadi, Pune) — product lifecycle engineering, freshers at ₹4.5–6 LPA; Mahindra & Mahindra vendors near Hinjewadi at ₹2.8–4 LPA; auto ancillary companies in Ranjangaon MIDC at ₹2.5–3.8 LPA; and engineering design outsourcing firms across Baner and Kharadi at ₹3–5 LPA. In Sambhajinagar, Tier-2 suppliers near Waluj and Shendra MIDC hire junior CAD engineers at ₹2.5–4 LPA. The good news is that strong Extrude/Revolve fundamentals combined with the rest of this series — assemblies, drawings, surface modeling — create a profile that earns ₹4.5–6.5 LPA even at the fresher stage at top employers.

Build Your NX 3D Modeling Foundation at ABC Trainings

ABC Trainings runs the Foundation to Expert NX CAD series as a structured progression — Episodes 1-6 build your sketching and interface skills, Episode 7 launches your 3D modeling career. Our trainers at Wagholi (Laxmi Datta Arcade, Pune) and Hadapsar (Shree Tower, Magarpatta) have industry experience modeling production parts for auto ancillaries in Pune's MIDC clusters, so every Extrude and Revolve exercise uses real industrial geometry. Weekend and evening batches at all four centers. Call 7039169629 or WhatsApp 7774002496 to enrol.

FAQs

What does NX CAD Episode 7 teach about Extrude and Revolve?

Episode 7 covers every parameter of both Extrude and Revolve in Siemens NX, including all six limit types (Value, Until Next, Until Last, Until Extended, Between Extents, Symmetric), draft angle and offset options for manufacturing, and Revolve axis selection, angle limits, and bi-directional operation — using industrial-realistic exercises throughout.

What is the difference between Extrude limit types Value and Until Next in NX?

Value extrudes by a fixed numerical distance that you specify. Until Next stops automatically at the first face the extrusion reaches in the model — so if you later change the wall thickness of a partition, the extrusion still stops at that partition without you editing it. Until Next is better for designs that will be revised; Value is simpler for final, stable geometry.

Can I apply draft angle in an NX Extrude operation directly?

Yes — NX Extrude has a built-in Draft tab where you specify the draft angle (in degrees) and the draft direction (from the sketch plane or from a reference face). The walls are automatically tapered as you extrude, producing a mold-ready part without any post-processing. You can choose inward or outward draft depending on the mold parting direction.

What types of parts are best modeled with Revolve in Siemens NX?

Revolve is best for axisymmetric parts: shafts, bearing housings, pulleys, gears (round blanks), valve bodies, pistons, flanges, pipe fittings, wheels, and any part whose cross-section is uniform when rotated around a central axis. If you can describe the part as 'what you get when you spin a 2D profile around a center line,' Revolve is the correct command.
